| Ouput Power: | |
|---|---|
BLE (Casambi, Tuya, Smart Life
Isolated
Constant Voltage
Dimming, CCT, Warm-dim, RGBCW
IP20, Dry & Damp
100-277VAC
60W
12/ 24/ 36/ 48V
CE, RoHS, REACH
60 Watt RGB CW 1 - 5 Channels BLE Dimmable Tuya Silvair Casambi LED Driver CV Lighting Control
Output: | Constant Voltage |
Range: | 100-277VAC |
PFC design: | Built-in active PFC function |
Efficiency: | Up to 88% |
Protections: | Short circuit/ over load/ over temperature |
Heat dissipation: | Cooling by free air convection |
Waterproof performance: | IP20(EU); for dry and damp locations(US) |
Dimming function: | TUYA Bluetooth wireless dim., which can be controller by Mobile App or Smart speaker, like Google home or Amazon echo. Adopt TUYA module, 8K Hz PWM output |
Dimming range: | 0-100% |
Application: | Suitable for the application of indoor LED lighting |
Warranty: | 5 years warranty |
Output Channel | Model Number | Output Voltage | Output Current | Output Power | Size | Weight |
1 Channel | KVB-12060-1C-JV2 | 12V | 5A | 60W | LED Driver Size | LED Driver Net Weight |
KVB-24060-1C-JV2 | 24V | 2.5A | ||||
KVB-36060-1C-JV2 | 36V | 1.67 | ||||
KVB-48060-1C-JV2 | 48V | 1.25A | ||||
2 Channels | KVB-12060-2C-JV2 | 12V | 5A | |||
KVB-24060-2C-JV2 | 24V | 2.5A | ||||
KVB-36060-2C-JV2 | 36V | 1.67 | ||||
KVB-48060-2C-JV2 | 48V | 1.25A | ||||
3 Channels | KVB-12060-3C-JV2 | 12V | 5A | |||
KVB-24060-3C-JV2 | 24V | 2.5A | ||||
KVB-36060-3C-JV2 | 36V | 1.67 | ||||
KVB-48060-3C-JV2 | 48V | 1.25A | ||||
4 Channels | KVB-12060-4C-JV2 | 12V | 5A | |||
KVB-24060-4C-JV2 | 24V | 2.5A | ||||
KVB-36060-4C-JV2 | 36V | 1.67 | ||||
KVB-48060-4C-JV2 | 48V | 1.25A | ||||
5 Channels | KVB-12060-5C-JV2 | 12V | 5A | |||
KVB-24060-5C-JV2 | 24V | 2.5A | ||||
KVB-36060-5C-JV2 | 36V | 1.67 | ||||
KVB-48060-5C-JV2 | 48V | 1.25A |
60 Watt RGB CW 1 - 5 Channels BLE Dimmable Tuya Silvair Casambi LED Driver CV Lighting Control
Output: | Constant Voltage |
Range: | 100-277VAC |
PFC design: | Built-in active PFC function |
Efficiency: | Up to 88% |
Protections: | Short circuit/ over load/ over temperature |
Heat dissipation: | Cooling by free air convection |
Waterproof performance: | IP20(EU); for dry and damp locations(US) |
Dimming function: | TUYA Bluetooth wireless dim., which can be controller by Mobile App or Smart speaker, like Google home or Amazon echo. Adopt TUYA module, 8K Hz PWM output |
Dimming range: | 0-100% |
Application: | Suitable for the application of indoor LED lighting |
Warranty: | 5 years warranty |
Output Channel | Model Number | Output Voltage | Output Current | Output Power | Size | Weight |
1 Channel | KVB-12060-1C-JV2 | 12V | 5A | 60W | LED Driver Size | LED Driver Net Weight |
KVB-24060-1C-JV2 | 24V | 2.5A | ||||
KVB-36060-1C-JV2 | 36V | 1.67 | ||||
KVB-48060-1C-JV2 | 48V | 1.25A | ||||
2 Channels | KVB-12060-2C-JV2 | 12V | 5A | |||
KVB-24060-2C-JV2 | 24V | 2.5A | ||||
KVB-36060-2C-JV2 | 36V | 1.67 | ||||
KVB-48060-2C-JV2 | 48V | 1.25A | ||||
3 Channels | KVB-12060-3C-JV2 | 12V | 5A | |||
KVB-24060-3C-JV2 | 24V | 2.5A | ||||
KVB-36060-3C-JV2 | 36V | 1.67 | ||||
KVB-48060-3C-JV2 | 48V | 1.25A | ||||
4 Channels | KVB-12060-4C-JV2 | 12V | 5A | |||
KVB-24060-4C-JV2 | 24V | 2.5A | ||||
KVB-36060-4C-JV2 | 36V | 1.67 | ||||
KVB-48060-4C-JV2 | 48V | 1.25A | ||||
5 Channels | KVB-12060-5C-JV2 | 12V | 5A | |||
KVB-24060-5C-JV2 | 24V | 2.5A | ||||
KVB-36060-5C-JV2 | 36V | 1.67 | ||||
KVB-48060-5C-JV2 | 48V | 1.25A |
